G80 Master Link A-344 (TH-93)
■ Powder coated, different color is available as per request.
■ Working load limit permanently shown on the body..
■ For use with chain, proof tested to 2.5 times of WLL, safety factor is 4:1.
■ For use with wire rope, proof tested to 2 times of WLL, safety factor is 5:1.
|
Size |
Chain Size |
Chain (4:1) |
Wire Rope(5:1) |
Dimension (mm) |
N.W. (kg/pc) |
||||
|
1 Leg W.L.L(t) |
2 Leg W.L.L(t) |
W.L.L(t) |
A |
B |
D |
S |
|||
|
7/16" |
1/4" |
1.12 |
1.6 |
1.6 |
100 |
60 |
12 |
6 |
0.27 |
|
9/32" |
1.5 |
- |
|||||||
|
1/2" |
9/32" |
1.5 |
2.12 |
2.5 |
100 |
60 |
14 |
7.6 |
0.38 |
|
5/16" |
2 |
- |
|||||||
|
11/16" |
5/16" |
2 |
2.8 |
4 |
160 |
90 |
18 |
8.4 |
0.85 |
|
3/8" |
3.15 |
- |
|||||||
|
3/4" |
3/8" |
3.15 |
4.25 |
6.5 |
160 |
90 |
20 |
10.4 |
1.2 |
|
1/2 |
5.3 |
- |
|||||||
|
7/8" |
1/2" |
5.3 |
7.5 |
8 |
180 |
100 |
22 |
13.5 |
1.63 |
|
5/8" |
8 |
- |
|||||||
|
1" |
5/8" |
8 |
11.2 |
11.5 |
180 |
100 |
25 |
16.5 |
2.13 |
|
3/4" |
11.2 |
- |
|||||||
|
1-1/8" |
3/4" |
12.5 |
- |
11.8 |
270 |
140 |
28 |
19 |
3.81 |
|
1-1/4" |
3/4" |
11.2 |
16 |
16 |
270 |
140 |
32 |
19 |
5.05 |
|
7/8" |
15 |
- |
|||||||
|
1-3/8" |
7/8" |
15 |
21.2 |
24 |
285 |
155 |
36 |
20 |
6.83 |
|
1" |
21.2 |
- |
|||||||
|
1-1/2" |
1-1/8" |
25 |
- |
25 |
300 |
160 |
40 |
26 |
8.9 |
|
1-3/4" |
1" |
21.2 |
30 |
31.5 |
340 |
180 |
45 |
26 |
12.8 |
|
1-1/4" |
31.5 |
- |
|||||||
|
2" |
1-1/4" |
31.5 |
45 |
45 |
390 |
215 |
51 |
32 |
17.3 |
|
