NITCHI ELECTRIC CHAIN HIOST
0.5t-5t
■ Solid steel construction
■ Heavy duty motor
■ Forged steel hooks
■ Push-button switch
■ Case-hardened load chain
HHB ELECTRIC CHAIN HIOST
0.5t-35t
■
Dual Braking System
Safe and More Reliable
Single Speed/Dual Speed
■ With dual braking system ensures safer and more reliable operation.
It is made of high-strength Al. alloy, compact design with light weight.
Dual-geared driven system enables smoothly driven with low noise.
High-strength alloy steel components with special heat treatment,
avoiding sudden break.
HHB Electric Chain Hoist With Motor Trolley
0.5t-25t
3-phase, 380v, 50Hz (Single Speed/Dual Speed)
HHB ELECTRIC CHAIN HOIST
LOW HEADROOM
WITH MOTOR TROLLEY AND MANUAL TROLLEY
0.5t-10t
LOW HEADROOM
3-phase, 380v, 50Hz (Single Speed/Dual Speed)
ELECTRIC CHAIN HIOST
TH-B
■Japan tech with dual braking system ensures safer and more reliable operation.
Compact design with light weight, high efficient operation.
High strength alloy steel components with special heat treatment, avoiding sudden break.
OPTIONAL FEATURES WITH EXTRA COST
■Dual speed
■Overload protection
■Different power supply and frequency
■FEC chain
■Thermal protection
■Urgent stop
Electric Trolley For TH-B Series Electric Chain Hoist
DC-A
ELECTRIC CHAIN HIOST
TH-B
■Japan tech with dual braking system ensures safer and more reliable operation.
Compact design with light weight, high efficient operation.
High strength alloy steel components with special heat treatment, avoiding sudden break.
OPTIONAL FEATURES WITH EXTRA COST
■Dual speed
■Overload protection
■Different power supply and frequency
■FEC chain
■Thermal protection
■Urgent stop
MINI ELECTRIC WIRE HOIST
■ With emergency stop switch
■ Reinforced braking switch with position limit
■ Protection class up to IP54
■ With thermal prevention device
ELECTRIC WIRE ROPE HOIST
CD1,MD1
■Model CD1,MD1 Electric Wire Hoist is a small-sized lifting equipment, which can be mounted on single beam, bridge, gantry and arm cranes.
■With slight modification, it can also be used as a winch.
■It is widely used in factories, mines, harbors, warehouses, cargo storage areas and shops, essential in raising working efficiency and improving working conditions.
■Model CD1 Electric Hoist has only normal speed, which can satisfy normal application.
■ Model MD1 Electric Hoist provides two speeds: normal speed and low speed. At a low speed, it can do precise loading and unloading the material for sand mould casting, maintenance of machine tools, etc.
Rope winding type of the hoist
Mounting patterns of fixed type hoist
Note:
A. The standard lifting height is 6,9,12,18,24,30 and 36 meters.
B. The lifting speed can be single speed or two speed, even multi-speed with frequency inverters.
C. The suitable rail for the low-headroom hoist is H-type rail, and I-type rail is also available.
D. The recommended rope reeving of this kind of hoist is 2/1, 4/2 or 4/1.
E. The normal traveling speed is 20m/min, and 12.5,16,25,32m/min by request
F. The normal rail gauge of the double-girder hoist is 1200, 1500,1800,2100 and 2300mm. The normal traveling speed of this kind of hoist is 20m/min,and 30, 45m/min by request.
Low Headroom Electric Hoist With Motor Trolley
Read More
SUSPENDING MINI ELECTRIC WINCH
DU
It is widely used for lifting, hoisting and dragging in warehouses, storage areas, factories, construction sites, etc.
Compact, light weight, economy and effective and easy to obtain 1-p power supply.
Dual brake system and high friction copper disc brakes enable high safety and long using life.
High strength heat treated alloy steel gear with its intensity three times higher than the rated capacity.
Adopt urgent stop switch and reinforced breaking switch with position limit.
Protection class up to Ip54.
It includes three series with different quality level: S, T, M series.
