G80 Welded Master Link Assembly with Flat (TH-96)
■ Powder coated, different color is available as per request.
■ Working load limit permanently shown on the body.
■ Max proof load is 2.5 times of the working load limited.
■ Min. Breaking strength is 4 times of the W.L.L.
|
Size |
W.L.L (t) |
B.L (t) |
Dimension (mm) |
N.W. (kg/pc) |
|||||
|
|
|
|
A |
B |
D |
a |
b |
d |
|
|
MA16 |
3.8 |
15.2 |
120 |
70 |
16 |
95 |
51 |
13 |
1.19 |
|
MA20 |
5.8 |
23.2 |
170 |
90 |
20 |
120 |
70 |
16 |
2.41 |
|
MA22 |
7.6 |
30.4 |
170 |
90 |
22 |
150 |
80 |
20 |
3.77 |
|
MA25 |
10 |
40 |
190 |
100 |
25 |
150 |
80 |
20 |
4.45 |
|
MA28 |
12.7 |
50.8 |
210 |
110 |
26 |
170 |
90 |
22 |
6.12 |
|
MA32 |
15.2 |
60.8 |
270 |
140 |
32 |
190 |
100 |
25 |
9.47 |
|
MA38 |
25 |
100 |
270 |
140 |
38 |
270 |
140 |
32 |
17.4 |
|
MA45 |
34 |
136 |
320 |
170 |
45 |
270 |
140 |
38 |
26.76 |
|
