Forged Pear Shape Link (TH-34)
■ Powder coated, different color is available as per request.
■ Working load limit permanently shown on the body.
■ Max proof load is 2.5 times of the working load limited.
|
Size (in) |
W.L.L (lbs) |
W.L.L (lbs) |
Dimension (mm) |
N.W. (kg/pc) |
|||
|
Alloy (5:1) |
Carbon (5:1) |
A |
B |
C |
D |
||
|
3/8" |
3600 |
1800 |
10 |
28.5 |
19 |
10 |
0.1 |
|
1/2" |
7000 |
2900 |
12.5 |
38 |
25.5 |
12.5 |
0.25 |
|
5/8" |
9000 |
4200 |
16 |
47.5 |
32 |
16 |
0.5 |
|
3/4" |
12300 |
6000 |
19 |
57 |
38 |
19 |
0.8 |
|
7/8" |
14000 |
8300 |
22 |
67 |
44.5 |
22.2 |
1.4 |
|
1" |
24360 |
10800 |
25 |
76 |
51 |
25.4 |
1.9 |
|
1-1/8" |
30600 |
12000 |
28 |
86 |
57 |
28.5 |
2.92 |
|
1-1/4" |
36000 |
16750 |
32 |
95 |
63.5 |
31.75 |
3.75 |
|
1-3/8" |
43000 |
20500 |
35 |
105 |
70 |
35 |
5.12 |
|
1-1/2" |
54300 |
25000 |
38 |
114 |
76 |
38 |
6.5 |
|
