G80 U.S Clevis Self-Locking Hook (TH-9)
■ Powder coated, different color is available as per request.
■ Working load limit permanently shown on the body.
■ Max proof load is 2.5 times of the working load limited.
■ Min. Breaking strength is 4 times of the W.L.L.
|
Size |
W.L.L (lbs) |
B.L (lbs) |
Dimension (mm) |
N.W.(kg/pc) |
|||||
|
A |
E |
Φ |
H |
K |
L |
||||
|
8-8 |
4500 |
18000 |
9.5 |
35 |
42 |
29.5 |
116.5 |
163.5 |
0.96 |
|
10-8 |
7100 |
28400 |
12 |
46 |
55 |
34.5 |
145 |
206 |
1.6 |
|
13-8 |
12000 |
48000 |
15 |
56 |
64 |
41.5 |
173 |
247 |
3.65 |
|
