G80 Clevis Grab Hook (TH-28)
■ Powder coated, different color is available as per request.
■ Working load limit permanently shown on the body.
■ Max proof load is 2.5 times of the working load limited.
■ Min. Breaking strength is 4 times of the W.L.L.
|
Size |
W.L.L (lbs) |
B.L (lbs) |
Dimension (mm) |
N.W. (kg/pc) |
|||||
|
|
|
|
A |
E |
B |
H |
K |
L |
|
|
1/4" |
3500 |
14000 |
10 |
9.5 |
38 |
23 |
65.3 |
106.5 |
0.66 |
|
3/8" |
7100 |
28400 |
12.7 |
13 |
46 |
31 |
82 |
137 |
1.43 |
|
1/2" |
12000 |
48000 |
16.5 |
16.5 |
61 |
41 |
113 |
184.5 |
3.75 |
|
5/8" |
18100 |
72400 |
20 |
20 |
68.5 |
49 |
129.5 |
215 |
5.52 |
|
3/4" |
28300 |
113200 |
24 |
24 |
88 |
58 |
152 |
254 |
9.35 |
|
7/8" |
34200 |
136800 |
27.5 |
26.5 |
101 |
66 |
178 |
295 |
13.67 |
|
