G80 Clevis Shortening Grab Hook (TH-86)
■ Powder coated, different color is available as per request.
■ Working load limit permanently shown on the body.
■ Max proof load is 2.5 times of the working load limited.
■ Min. Breaking strength is 4 times of the W.L.L.
|
Size |
W.L.L (t) |
B.L (t) |
Dimension (mm) |
N.W. (kg/pc) |
|||
|
|
|
|
E |
A |
H |
L |
|
|
6-8 |
1.12 |
4.48 |
8 |
8 |
16 |
75 |
0.25 |
|
7/8-8 |
2.0 |
8.0 |
10.8 |
9.5 |
21.6 |
90 |
0.32 |
|
10-8 |
3.15 |
12.6 |
13.5 |
12.5 |
30 |
126 |
0.73 |
|
13-8 |
5.3 |
21.2 |
16.5 |
15 |
42.5 |
163.5 |
1.6 |
|
16-8 |
8 |
32 |
19.2 |
19.5 |
45.5 |
183.5 |
2.8 |
|
20-8 |
12.5 |
50 |
24 |
24 |
56 |
219 |
5.0 |
|
22-8 |
15 |
60 |
27 |
27 |
68.5 |
254 |
6.3 |
|
