G80 European Type Eye Self-Locking Hook (TH-81)
■ Powder coated, different color is available as per request.
■ Working load limit permanently shown on the body.
■ Max proof load is 2.5 times of the working load limited.
■ Min. Breaking strength is 4 times of the W.L.L.
|
Size |
W.L.L (t) |
B.L (t) |
Dimension (mm) |
N.W. (kg/pc) |
|||||
|
|
|
|
Φ1 |
R |
D |
Φ2 |
H |
E |
|
|
6-8 |
1.12 |
4.48 |
22 |
110.5 |
10 |
34 |
19.5 |
28 |
0.5 |
|
7/8-8 |
2.0 |
8.0 |
25 |
136 |
12 |
46 |
24 |
34 |
0.8 |
|
10-8 |
3.15 |
12.6 |
32 |
171 |
15 |
56 |
28.5 |
44 |
1.55 |
|
13-8 |
5.3 |
21.2 |
40.5 |
208.5 |
19.5 |
69 |
40 |
52 |
3.2 |
|
16-8 |
8 |
32 |
56 |
257.5 |
22 |
86 |
50.5 |
60 |
5.74 |
|
20-8 |
12.5 |
50 |
64.5 |
275 |
27 |
100 |
55 |
81 |
8.5 |
|
22-8 |
15 |
60 |
70 |
320 |
30 |
98 |
67 |
82 |
13 |
|
26-8 |
21.2 |
84.8 |
80 |
363 |
34 |
110 |
75 |
110 |
18 |
|
32-8 |
31.5 |
126 |
105 |
472 |
45 |
166 |
97 |
168 |
44.5 |
|
