G80 Master Link Assemblies (TH-32)
■ Powder coated, different color is available as per request.
■ Working load limit permanently shown on the body.
■ Max proof load is 2.5 times of the working load limited.
■ Min. Breaking strength is 4 times of the W.L.L.
|
Size |
W.L.L (t) |
B.L (t) |
Dimension (mm) |
N.W. (kg/pc) |
|||||||
|
A |
B |
D |
a |
b |
d |
s |
H |
||||
|
6-8 |
2.36 |
9.44 |
135 |
75 |
18 |
54 |
25 |
13 |
7 |
25 |
1.18 |
|
7-8 |
3.15 |
12.6 |
135 |
75 |
18 |
60 |
38 |
13 |
7 |
25 |
1.24 |
|
8-8 |
4.25 |
17 |
160 |
90 |
22 |
70 |
34 |
16 |
7 |
25 |
2.2 |
|
10-8 |
6.7 |
26.8 |
180 |
100 |
26 |
85 |
40 |
18 |
11 |
35 |
3.4 |
|
13-8 |
11.2 |
44.8 |
200 |
110 |
32 |
115 |
50 |
22 |
13 |
35 |
6.1 |
|
16-8 |
17 |
68 |
260 |
140 |
36 |
140 |
65 |
26 |
17 |
45 |
9.98 |
|
18-8 |
21.2 |
84.8 |
340 |
180 |
45 |
180 |
100 |
32 |
- |
- |
18.9 |
|
20-8 |
26.5 |
106 |
350 |
190 |
50 |
180 |
100 |
32 |
- |
- |
22.6 |
|
22-8 |
31.5 |
126 |
350 |
190 |
50 |
180 |
100 |
36 |
- |
- |
25.2 |
|
26-8 |
45 |
180 |
400 |
200 |
56 |
200 |
110 |
40 |
- |
- |
34.26 |
|
28-8 |
50 |
200 |
430 |
220 |
63 |
200 |
110 |
45 |
- |
- |
47.11 |
|
32-8 |
63 |
252 |
460 |
250 |
72 |
200 |
110 |
50 |
- |
- |
66.46 |
|
