G80 Clevis Slip Hook (TH-329)
■ Powder coated, different color is available as per request.
■ Working load limit permanently shown on the body.
■ Max proof load is 2.5 times of the working load limited.
■ Min. Breaking strength is 4 times of the W.L.L.
Size |
W.L.L |
B.L. |
Dimension (mm) |
N.W. (kg/pc) |
||||
(t) |
(t) |
A |
B |
E |
M |
L |
||
6-8 |
1.12 |
4.48 |
7.5 |
32 |
22 |
74 |
121 |
0.40 |
7/8-8 |
2 |
8 |
9 |
36 |
25.5 |
83 |
137 |
0.52 |
10-8 |
3.15 |
12.6 |
12 |
46 |
34 |
107 |
175.5 |
0.95 |
13-8 |
5.3 |
21.2 |
15 |
59 |
41.5 |
134 |
210.5 |
1.97 |
16-8 |
8 |
32 |
17.5 |
70 |
46 |
158 |
248 |
3.45 |
18/20-8 |
12.5 |
50 |
23 |
80 |
52 |
189 |
309 |
6.50 |
22-8 |
15 |
60 |
25.5 |
98 |
60 |
239 |
375.5 |
9.65 |
