G80 European Swivel Self-Locking Hook (TH-83)
■ Powder coated, different color is available as per request.
■ Working load limit permanently shown on the body.
■ Max proof load is 2.5 times of the working load limited.
■ Min. Breaking strength is 4 times of the W.L.L.
|
Size |
W.L.L (t) |
B.L (t) |
Dimension(mm) |
N.W. (kg/pc) |
|||||
|
B |
C |
D |
L |
T |
E |
||||
|
6-8 |
1.12 |
4.48 |
32.5 |
22 |
11.25 |
170 |
34 |
29 |
0.71 |
|
7/8-8 |
2.0 |
8.0 |
35.5 |
26 |
12.5 |
210 |
46 |
34 |
1.1 |
|
10-8 |
3.15 |
12.6 |
42 |
34 |
15 |
247 |
56 |
44 |
2.0 |
|
13-8 |
5.3 |
21.2 |
50 |
38.5 |
16 |
302 |
69 |
52 |
4.0 |
|
16-8 |
8 |
32 |
61 |
55 |
21.5 |
383 |
86 |
60 |
7.3 |
|
20-8 |
12.5 |
50 |
72 |
61 |
26 |
418 |
100 |
83 |
11.6 |
|
22-8 |
15 |
60 |
95 |
95 |
33 |
527 |
98 |
88 |
16.0 |
|
26-8 |
21.2 |
84.8 |
122 |
115 |
42 |
610 |
110 |
95.5 |
21.5 |
|
32-8 |
31.5 |
126 |
140 |
146 |
52 |
777 |
166 |
150 |
79 |
|
