G80 Master Link Assembly A-345 (TH-92)
■ Powder coated, different color is available as per request.
■ Working load limit permanently shown on the body.
■ Max proof load is 2.5 times of the working load limited.
■ Min. Breaking strength is 5 times of the W.L.L.
|
Size |
W.L.L (t) |
B.L (t) |
Dimension (mm) |
N.W. (kg/pc) |
||||||
|
|
|
|
A |
B |
D |
a |
b |
d |
s |
|
|
3/4" |
4.1 |
20.5 |
140 |
70 |
20 |
85 |
40 |
14 |
7.6 |
1.55 |
|
1" |
8.4 |
42 |
178 |
89 |
25 |
100 |
60 |
18 |
8.4 |
3.29 |
|
1-1/4" |
14.1 |
70.5 |
220 |
110 |
32 |
100 |
60 |
22 |
13.5 |
7.18 |
|
1-1/2" |
21.3 |
106.5 |
267 |
135 |
38 |
180 |
100 |
28 |
16.5 |
12.91 |
|
1-3/4" |
33.3 |
166.5 |
305 |
152 |
45 |
180 |
100 |
35 |
18.5 |
21.25 |
|
2" |
40.3 |
201.5 |
356 |
178 |
50 |
180 |
100 |
38 |
- |
30.34 |
|
