Forged Round Ring (TH-38)
■ Powder coated, different color is available as per request.
■ Working load limit permanently shown on the body.
■ Max proof load is 2.5 times of the working load limited.
■ Min. Breaking strength is 6 times of the W.L.L.
|
Size |
W.L.L |
B.L |
Dimension(mm) |
N.W. |
|
|
(inch) |
(t) |
(t) |
A |
B |
(kg/pc) |
|
3/8x2 |
0.5 |
3 |
10 |
50 |
0.11 |
|
1/2x2 |
1 |
6 |
13 |
50 |
0.21 |
|
5/8x3 |
1.5 |
9 |
16 |
76 |
0.46 |
|
5/8x3-5/16 |
1.5 |
9 |
16 |
84 |
0.5 |
|
3/4x3 |
2.3 |
13.8 |
19 |
76 |
0.67 |
|
3/4x4 |
2.5 |
15 |
19 |
102 |
0.84 |
|
7/8x4 |
3.3 |
19.8 |
22 |
102 |
1.2 |
|
7/8x5-1/2 |
2.5 |
15 |
22 |
140 |
1.55 |
|
1x4 |
4.9 |
29.4 |
25 |
102 |
1.59 |
|
1x5-1/2 |
4.9 |
29.4 |
25 |
140 |
2.1 |
|
1-1/8x6 |
4.7 |
28.2 |
28 |
152 |
2.87 |
|
1-1/4x5 |
7.7 |
46.2 |
32 |
127 |
3.1 |
|
1-1/4x6 |
7.7 |
46.2 |
32 |
152 |
3.6 |
|
1-1/4x10 |
7.7 |
46.2 |
32 |
254 |
5.6 |
|
1-3/8x6 |
8.6 |
51.6 |
35 |
152 |
4.5 |
|
1-1/2x8 |
11.3 |
67.8 |
38 |
203 |
6.8 |
|
1-1/2x8-3/4 |
11.3 |
67.8 |
38 |
222 |
7.32 |
|
1-1/2x10 |
11.3 |
67.8 |
38 |
254 |
8.22 |
|
2x12 |
15.9 |
95.4 |
50 |
305 |
17.8 |
|
